Showing the latest version of manual and documents for RedMax BCZ260S. For earlier versions, see link below to search all manuals & documents.
Specifications
Specifications
BCZ260S 967 19 43‑01 | |
|---|---|
Engine | |
Cylinder displacement | 1.55 cu.inch |
Clutch engagement speed (±120) | 4,000 rpm |
Electrode gap | 0.03 in |
Fuel Consumption | 450 g/kWh |
Fuel tank volume | 22.32 fl oz |
Fuel tank volume | 0.66 l |
Idling speed | 3,000 rpm |
Maximum rpm output shaft | 8,208 rpm |
Output shaft power | 1.27 hp |
Spark Plug | NGK BPMR8Y |
Torque, max. | 1.24 Nm |
Torque, max. at rpm | 7,000 rpm |
BCZ260S 967 19 43‑01 | |
|---|---|
Product data | |
Drive gear angle | 60 ° |
Gear ratio | 1.462 |
BCZ260S 967 19 43‑01 | |
|---|---|
Emission | |
Exhaust emissions (CO average) CARB | 354.3 g/kWh |
BCZ260S 967 19 43‑01 | |
|---|---|
Dimensions | |
Weight (excl. cutting equipment) | 10.8 lbs |
