Parts, manuals and support for BCZ265S
All the support you need for BCZ265S. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to BCZ265S product pageChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
BEVEL GEAR
Article
Art. number
Support content
Manuals & Documents
(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for RedMax BCZ265S. For earlier versions, see link below to search all manuals & documents.
Specifications
Specifications
BCZ265S 970 44 69‑01 | |
|---|---|
Engine | |
Cylinder displacement | 1.55 cu.inch |
Clutch engagement speed (±120) | 4,000 rpm |
Electrode gap | 0.02 in |
Fuel Consumption | 600 g/kWh |
Fuel tank volume | 21.98 fl oz (US) |
Fuel tank volume | 0.65 l |
Idling speed | 3,000 rpm |
Maximum rpm output shaft | 6,500 rpm |
Output shaft power | 1.34 hp |
Spark Plug | Husqvarna HQT-2 |
Torque, max. | 1.2 Nm |
Torque, max. at rpm | 6,000 rpm |
BCZ265S 970 44 69‑01 | |
|---|---|
Product data | |
Drive gear angle | 30 ° |
Gear ratio | 19 |
BCZ265S 970 44 69‑01 | |
|---|---|
Sound and noise | |
Sound power level, guaranteed (LWA) | 107 dB(A) |
Sound pressure level at operators ear | 98 dB(A) |
BCZ265S 970 44 69‑01 | |
|---|---|
Dimensions | |
Weight (excl. cutting equipment) | 10.58 lbs |
