Hedge trimmers

Parts, manuals and support for CHTZ60

All the support you need for CHTZ60. Manuals, spare parts, guides, how-to’s, and more.

Currently available

Choose article number

To show you the right support, choose an article number from this list.

Article number

Support content

(2)

Showing the latest version of manual and documents for RedMax CHTZ60. For earlier versions, see link below to search all manuals & documents.

Engine - Compare specifications across different product articles
Engine	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Cylinder displacement	1.3 cu.inch
Electrode gap	0.02 in
Fuel tank volume	10.14 fl oz
Idling speed	2,900 rpm
Maximum power speed	7,800 rpm
Output shaft power	0.8 hp
Spark Plug	Husqvarna HQT-4 672201

Capacity - Compare specifications across different product articles
Capacity	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Cutting speed	4,400 cut/min

Vibration - Compare specifications across different product articles
Vibration	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Equivalent vibration level (ahv, eq) front handle	4.4 m/s²
Equivalent vibration level (ahv, eq) rear handle	4.3 m/s²

Equipment - Compare specifications across different product articles
Equipment	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Knife length	24 in

Sound and noise - Compare specifications across different product articles
Sound and noise	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Sound power level, guaranteed (LWA)	102 dB(A)
Sound pressure level at operators ear (LpA)	98 dB(A)

Dimensions - Compare specifications across different product articles
Dimensions	CHTZ60 HEDGE TRIMMER Article Number: 967 68 19‑01
Weight	11.5 lbs
