Zero Turn Mowers
Parts, manuals and support for CZT72x
All the support you need for CZT72x. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
FUEL TANK
Article
Art. number
Support content
Manuals & Documents
(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for RedMax CZT72x. For earlier versions, see link below to search all manuals & documents.
Specifications
Specifications
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Engine | |
Cylinder displacement | 61 cu.inch |
Cylinders | 2 |
Engine lubrication type | Full pressure |
Engine name | FX Series |
Fuel tank location | Side (Dual) |
Fuel tank volume (with reserve) | 11 gal (US) |
Engine brand | Kawasaki |
Motor/engine manufacturer | Kawasaki |
Power/fuel type | Gasoline |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Equipment | |
Cup holder | Yes |
Seat back height | High |
Seat type | Professional, suspension |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Cutting deck | |
Anti-scalp wheels | 6 |
Blade engagement | Electric clutch |
Blades | 3 pcs |
Cutting deck material | Steel |
Cutting deck type | 7-gauge fabricated |
Cutting methods | Collect/Mulch/Side discharge |
Cutting width | 72 in |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Capacity | |
Speed forward max | 12 mph |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Drive system | |
Transmission Brand | Hydro-Gear/Parker |
Transmission model | PR/TL |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Dimensions | |
Base machine, height | 47.5 in |
Base machine, length | 86 in |
Base machine, width | 53.5 in |
Weight | 1,400 lbs |
