TRZ230

Trimmers

Parts, manuals and support for TRZ230S

All the support you need for TRZ230S. Manuals, spare parts, guides, how-to’s, and more.

Currently available
Go to TRZ230S product page
Choose article number
To show you the right support, choose an article number from this list.

Support content

Specifications

Engine - Compare specifications across different product articles
Engine
TRZ230S
Article Number: 967 19 41‑01

Cylinder displacement

1.37 cu.inch

Clutch engagement speed (±120)

4,000 rpm

Electrode gap

0.03 in

Fuel Consumption

450 g/kWh

Fuel tank volume

21.64 fl oz

Idling speed

3,000 rpm

Maximum rpm output shaft

8,208 rpm

Output shaft power

0.94 hp

Spark Plug

NGK BPMR8Y

Torque, max.

1 Nm

Torque, max. at rpm

6,500 rpm
Product data - Compare specifications across different product articles
Product data
TRZ230S
Article Number: 967 19 41‑01

Drive gear angle

60 °

Gear ratio

1.462
Emission - Compare specifications across different product articles
Emission
TRZ230S
Article Number: 967 19 41‑01

Exhaust emissions (CO average) CARB

495.18 g/kWh
Dimensions - Compare specifications across different product articles
Dimensions
TRZ230S
Article Number: 967 19 41‑01

Weight (excl. cutting equipment)

10.14 lbs
