Showing the latest version of manual and documents for RedMax SRTZ235. For earlier versions, see link below to search all manuals & documents.

Engine - Compare specifications across different product articles
Engine	Articulated pole HT Article Number: 970 55 02‑01
Cylinder displacement	1.37 cu.inch
Electrode gap	0.03 in
Fuel tank volume	21.64 fl oz
Idling speed	3,000 rpm
Maximum power speed	8,500 rpm
Output shaft power	0.94 hp
Spark Plug	NGK BPMR8Y

Capacity - Compare specifications across different product articles
Capacity	Articulated pole HT Article Number: 970 55 02‑01
Cutting speed	4,400 cut/min

Vibration - Compare specifications across different product articles
Vibration	Articulated pole HT Article Number: 970 55 02‑01
Equivalent vibration level (ahv, eq) front handle	9.3 m/s²
Equivalent vibration level (ahv, eq) rear handle	11.2 m/s²

Equipment - Compare specifications across different product articles
Equipment	Articulated pole HT Article Number: 970 55 02‑01
Knife length	24 in

Dimensions - Compare specifications across different product articles
Dimensions	Articulated pole HT Article Number: 970 55 02‑01
Weight	12.5 lbs
