Specifications
Specifications
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Engine | |
Cylinder displacement | 61 cu.inch |
Cylinders | 2 |
Engine lubrication type | Full pressure |
Engine name | FX Series |
Fuel tank location | Side (Dual) |
Fuel tank volume (with reserve) | 11 gal (US) |
Engine brand | Kawasaki |
Motor/engine manufacturer | Kawasaki |
Power/fuel type | Gasoline |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Equipment | |
Cup holder | Yes |
Seat back height | High |
Seat type | Professional, suspension |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Cutting deck | |
Anti-scalp wheels | 6 |
Blade engagement | Electric clutch |
Blades | 3 pcs |
Cutting deck material | Steel |
Cutting deck type | 7-gauge fabricated |
Cutting methods | Collect/Mulch/Side discharge |
Cutting width | 72 in |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Capacity | |
Speed forward max | 12 mph |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Drive system | |
Transmission manufacturer | Hydro-Gear/Parker |
Transmission model | PR/TL |
2020 Model, Pump and Motor Drive 967 94 35‑01 | |
|---|---|
Dimensions | |
Base machine, height | 47.5 in |
Base machine, length | 86 in |
Base machine, width | 53.5 in |
Weight | 1,400 lbs |
